5 Sizes Inflatable Spray Booth Tent Inflatable Paint Booth Tent Car Paint Booth Giant Workstation
For EU and USA customers :We have warehouse in EU and USA ,You can place an order directly, we will deliver it to your door, there is no tariff. Normally,you can receive them within one to two weeks after we ship all the goods
【SIZE】 - Here are 5 different sizes for you to choose. The generous capacity creates a new space effect.
【2 HIGH POWER FANS】 - CE / DL 330W and 680W fans included. The workstation structure is inflated in 3-5 minutes. The other offers a new working environment.
【STRONG & DURABLE】 - Cabin body made of professional 210D oxford cloth and 0.4 PVC material, resistant to moisture, UV, flame and can be worn.
【HIGH STABILITY】 - D-rings are attached to the cab body. Six 3.5m (11.5ft) ropes, six 40cm (15.7in) stakes and eight sandbags (sand not included) provide stability during use.
【CONVENIENT USE】 -With an air wall structure frame, this automotive spray booth has the advantages of light weight, low inlet and small folded size, easy to carry and convenient to use.
Features & Details:
Style: inflatable spray paint booth tent
Product appearance: Tent
Material: 210D oxford cloth, 0.4mm PVC
Input voltage: 220V AC
Inflation Fan Power: 330W
Ventilation fan power: 680W/1100W
1 inflatable tent
1 330W inflation fan
1 ventilation fan of 680W or 1100W
Ropes 4 X 11.5 '(3.5 m)
4 x 10 "(25 cm) stake
8 sandbags (without sand)
13ft x 8ft x 7ft (approximately 4 x 2.5 x 2m)
19.8ft x 9.8ft x 8.2ft (approximately 6 x 3 x 2.5m)
26ft x 13ft x 10ft (approximately 8 x 4 x 3m)
26ft x 15ft x 10ft (approximately 8 x 4.5 x 3m)
39.3ft x 16.4ft x 13.1ft (approximately 12 x 5 x 4m)
Instructions for use
1. Spread the inflatable equipment flat on the ground. If the ground is smooth, you can spread it directly; if the ground contains sharp objects such as rubble, you need to lay a protective layer on the ground (such as colored striped cloth, tarpaulin, canvas, etc.).
2. This product needs to be wired, installed and maintained by a professional electrician in accordance with national regulations on safe electricity use.
3. Check the total power of the fan and whether the sub-cables match.
4. Use the fan according to the fan manual. Check if the fan is loose, turn the fan blade to check if there is any peculiar smell, and then turn on the power to test the machine.
5. If you need to use multiple fans at the same time, you can start them one by one, wait for the previous fan to run for 20-30 seconds before starting the next one.
6. The new equipment has less air leakage. In the first period, you only need to tie a part of the fan port. Later, depending on the softness and hardness of the equipment, gradually tie up all the fan ports.
7. At the end of use, the power should be turned off first, and then the fan opening of the device should be unlocked. After the fan blades stop rotating, the fan should be removed, and the device should be folded again after 10 minutes.
It is recommended to use it on sunny days. When using it on rainy days, keep the fan in a dry place that is not exposed to rain to prevent damage to the fan due to water ingress. It is recommended not to use this product in an environment where the wind is greater than 6 levels to prevent the product from being damaged by excessive wind. If you need to use heating and other insulation equipment in the tent, please make sure that the temperature of the equipment is below 60 degrees Celsius
Daily maintenance of inflatable tents
When inflatable products are in use, you need to take off your shoes and sharp objects on your body before you can go up and play.
Do not move the product frequently. If you drag it close to the ground, it will wear out after a long time.
Keep away from fireworks. On the occasion of the opening celebration, salutes and fireworks are inseparable. Please be sure to stay away from fireworks for more than 6 meters when using it.
If it is dirty,please wipe it with a damp soft cloth
In case of severe weather such as strong wind, rain, snow, fog, hail, etc., the equipment should be strictly prohibited to use to avoid accidents.
If you do not use this tent for a long time, you should fold, bundle, and pack the clean equipment. The storage temperature is generally between -50 and +40 degrees Celsius. Please pay attention to prevent the equipment from biting by rodents and insects.
Taicang Vevor Machinery Equipment CO.,LTD.We operates more than 1000 kinds of machinery equipment products,and engaged in cross-border business for 10 years.At present,we have more than 200 employees.
Our concept isMarket-oriented, based on the customer service
Through years of practice,we have accumulated valuable experience in the mechanical equipment industry,which gives us the opportunity to serve companies from different countries. In the future,we will give full play to our strengths in the mechanical equipment industry,and actively participate in the construction ofthe Silk Road Economic Belt and the 21st-Century Maritime Silk Roadto share high-quality production capacity and mutual benefit.
Brand Name: VEVOR
Power (W): 500w
Voltage (V): 220V
Model Number: ZP6X3X2.5MHS
